Kimyasal Elementler İçin Kullanılan Sembol ve Kısaltmalar	Mekanik Testler İçin Kullanılan Sembol ve Kısaltmalar
Sembol	Element	Sembol	Element
C	Karbon	Re	Akma mukavemeti (N/mm 2)
Mn	Mangan	Rm	Çekme mukavemeti (N/mm 2 )
P	Fosfor	Rp0,2	Yüksek sıcaklıkta akma mukavemeti (N/mm 2)
S	Kükürt	A	Uzama (%)
Si	Silisyum	A5	Uzama (L0 =5,65x√S 0 )
Al	Alüminyum	A50	Uzama (L 0 =50 mm)
Cu	Bakır	A80	Uzama (L 0 =80 mm)
N	Azot	A100	Uzama (L 0 =100 mm)
O	Oksijen	A200	Uzama (L 0 =200 mm)
H	Hidrojen	S 0	Test numunesinin kesit alanı (mm 2
Ca	Kalsiyum	L 0	Test numunesinin ilk ölçü uzunluğu (mm)
Ti	Titanyum	d	Nominal kalınlık (mm)
V	Vanadyum	t	Ton
Cr	Krom	Darbe	Darbe testi
Ni	Nikel	KVc	Darbe enerjisi, Joule (J)
Mo	Molibden	Sıc.	Test sıcaklığı (0C)
Nb	Niyobyum	Katlama	Katlama testi
B	Bor	kmy	Katlama mandrel yarıçapı (mm)
Sn	Kalay	kmç	Katlama mandrel çapı (mm)
Fe	Demir	en	Enine test numunesi
Zn	Çinko	boy.	Boyuna test numunesi
Pb	Kurşun	HRB	B sertliği
As	Arsenik	ppm	Milyonda bir
W	Tungsten	DWTT	Düşürme ağırlıklı yırtılma testi
Zr	Zirkonyum	Std.	Standart

H-1 PAKETLEME ⇓

Size	Unit Weight kg/mt	6 METERS						12 METERS
Size	Unit Weight kg/mt	Width		Height	Pieces per bundle	Theoric Bundle	Six meters weight	Width		Height	Pieces Per Bundle	Theoric Bundle	Twelve Meters Weight
L 30X30X2,8	1.28	9	X	23	383	2,937	7.7	9	X	11	179	2,745	15.3
L 30X30X3	1.36	9	X	22	366	2,993	8.2	9	X	11	179	2,928	16.4
L 30X30X3,5	1.57	9	X	19	315	2,973	9.4	9	X	9	145	2,737	18.9
L 30X30X4	1.78	9	X	17	281	2,999	10.7	9	X	8	128	2,733	21.3
L 30X30X5	2.18	9	X	13	213	2,786	13.1	9	X	7	111	2,904	26.2
L 35X35X3	1.60	8	X	21	308	2,955	9.6	8	X	10	143	2,744	19.2
L 35X35X3,5	1.85	8	X	18	263	2,916	11.1	8	X	9	128	2,839	22.2
L 35X35X4	2.09	8	X	16	233	2,926	12.6	8	X	8	113	2,838	25.1
L 40X40X3	1.84	7	X	21	267	2,954	11.1	7	X	10	124	2,744	22.1
L 40X40X3,5	2.13	7	X	18	228	2,917	12.8	7	X	9	111	2,840	25.6
L 40X40X3,8	2.30	7	X	17	215	2,971	13.8	7	X	8	98	2,708	27.6
L 40X40X4	2.42	7	X	16	202	2,929	14.5	7	X	8	98	2,842	29.0
L 40X40X5	2.97	7	X	13	163	2,909	17.8	7	X	6	72	2,570	35.7
L 44X44X3,2	2.10	7	X	18	228	2,873	12.6	7	X	9	111	2,797	25.2
L 44X44X4,8	3.10	7	X	12	150	2,790	18.6	7	X	6	72	2,678	37.2
L 45X45X3	2.09	6	X	22	237	2,972	12.5	6	X	11	116	2,909	25.1
L 45X45X4	2.74	6	X	17	182	2,994	16.5	6	X	8	83	2,731	32.9
L 45X45X5	3.38	6	X	13	138	2,797	20.3	6	X	7	72	2,919	40.5
L 50X50X4	3.06	6	X	15	160	2,934	18.3	6	X	7	72	2,640	36.7
L 50X50X4,8	3.63	6	X	12	127	2,765	21.8	6	X	6	61	2,656	43.5
L 50X50X5	3.77	6	X	12	127	2,873	22.6	6	X	6	61	2,760	45.2
L 50X50X5,5	4.12	6	X	11	116	2,868	24.7	6	X	5	50	2,473	49.5
L 50X50X6	4.47	6	X	10	105	2,815	26.8	6	X	5	50	2,681	53.6
L 50X50X7	5.15	6	X	9	94	2,906	30.9	6	X	4	39	2,411	61.8
L 51X51X3,2	2.40	6	X	19	204	2,938	14.4	6	X	9	94	2,707	28.8
L 51X51X4,8	3.60	6	X	13	138	2,981	21.6	6	X	6	61	2,635	43.2
L 55X55X4	3.38	5	X	16	140	2,841	20.3	5	X	8	68	2,760	40.6
L 55X55X5	4.17	5	X	13	113	2,831	25.1	5	X	7	59	2,956	50.1
L 60X60X3,8	3.52	5	X	16	140	2,957	21.1	5	X	8	68	2,872	42.2
L 60X60X4	3.70	5	X	15	131	2,905	22.2	5	X	7	59	2,617	44.4
L 60X60X4,5	4.13	5	X	13	113	2,803	24.8	5	X	7	59	2,927	49.6
L 60X60X5	4.57	5	X	12	104	2,850	27.4	5	X	6	50	2,741	54.8
L 60X60X5,8	5.25	5	X	11	95	2,994	31.5	5	X	5	41	2,584	63.0
L 60X60X6	5.42	5	X	10	86	2,798	32.5	5	X	5	41	2,668	65.1
L 60X60X7	6.26	5	X	9	77	2,894	37.6	5	X	4	32	2,405	75.2
L 60X60X8	7.09	5	X	8	68	2,893	42.5	5	X	4	32	2,723	85.1
L 64X64X4,8	4.60	4	X	15	102	2,815	27.6	4	X	8	53	2,926	55.2
L 64X64X6,4	6.10	4	X	12	81	2,965	36.6	4	X	6	39	2,855	73.2
L 65X65X4	4.03	4	X	17	116	2,801	24.2	4	X	9	60	2,898	48.3
L 65X65X5	4.97	4	X	14	95	2,835	29.8	4	X	7	46	2,746	59.7
L 65X65X6	5.91	4	X	12	81	2,872	35.5	4	X	6	39	2,765	70.9
L 65X65X7	6.83	4	X	10	67	2,744	41.0	4	X	5	32	2,622	81.9
L 65X65X8	7.71	4	X	9	60	2,776	46.3	4	X	5	32	2,961	92.5
L 70X70X5	5.37	4	X	13	88	2,834	32.2	4	X	7	46	2,963	64.4
L 70X70X6	6.38	4	X	11	74	2,833	38.3	4	X	6	39	2,986	76.6
L 70X70X7	7.38	4	X	10	67	2,966	44.3	4	X	5	32	2,833	88.5
L 70X70X8	8.36	4	X	8	53	2,658	50.1	4	X	4	25	2,507	100.3
L 75X75X5	5.78	4	X	12	81	2,807	34.7	4	X	6	39	2,703	69.3
L 75X75X6	6.87	4	X	10	67	2,761	41.2	4	X	5	32	2,637	82.4
L 75X75X7	7.94	4	X	9	60	2,859	47.7	4	X	4	25	2,383	95.3
L 75X75X8	9.00	4	X	8	53	2,863	54.0	4	X	4	25	2,701	108.0
L 75X75X10	11.07	4	X	6	39	2,591	66.4	4	X	3	18	2,392	132.9
L 76X76X4,8	5.50	4	X	13	88	2,904	33.0	4	X	6	39	2,574	66.0
L 76X76X6,4	7.30	4	X	10	67	2,935	43.8	4	X	5	32	2,803	87.6
L 76X76X7,9	9.10	4	X	8	53	2,894	54.6	4	X	4	25	2,730	109.2
L 80X80X6	7.34	3	X	14	68	2,994	44.0	3	X	7	33	2,906	88.1
L 80X80X7	8.49	3	X	12	58	2,955	51.0	3	X	6	28	2,853	101.9
L 80X80X8	9.63	3	X	10	48	2,773	57.8	3	X	5	23	2,658	115.6
L 80X80X10	11.86	3	X	8	38	2,704	71.2	3	X	4	18	2,562	142.3
UPN 50	3.86	7	X	8	112	2,594	23.2	7	X	4	56	2,594	46.3
UPN 65	7.09	5	X	6	60	2,552	42.5	5	X	3	30	2,552	85.1
UPN 80	8.64	4	x	6	48	2,488	51.8	4	x	3	24	2,488	103.7
IPN 80	5.94	4	X	7	56	1,996	35.6	4	X	5	40	2,851	71.3
IPE 80	6.00	4	X	7	56	2,016	36.0	4	X	5	40	2,880	72.0

H-2 PAKETLEME ⇓

Size	Unit Weight kg/mt	6 METERS						12 METERS
Size	Unit Weight kg/mt	Width		Height	Pieces Per Bundle	Theoric Bundle (kg)	Six Meters Weight (kg)	Width		Height	Pieces Per Bundle	Theoric Bundle (kg)	Six Meters Weight (kg)
L 89X89X7,9	10.70	3	x	9	43	2,761	64.2	3	x	5	23	2,953	128.4
L 89X89X9,5	12.60	3	x	8	38	2,873	75.6	3	x	4	18	2,722	151.2
L 90X90X7	9.61	3	x	10	48	2,767	57.6	3	x	5	23	2,652	115.3
L 90X90X8	10.90	3	x	9	43	2,813	65.4	3	x	4	18	2,355	130.8
L 90X90X9	12.18	3	x	8	38	2,778	73.1	3	x	4	18	2,632	146.2
L 90X90X10	13.45	3	x	7	33	2,663	80.7	3	x	4	18	2,905	161.4
L 100X100X9	13.62	3	x	7	33	2,696	81.7	3	x	4	18	2,941	163.4
L 100X100X10	15.04	3	x	7	33	2,977	90.2	3	x	3	13	2,346	180.4
L 100X100X12	17.83	3	x	6	28	2,996	107.0	3	x	3	13	2,782	214.0
L 102X102X9,5	14.60	3	x	7	33	2,891	87.6	3	x	3	13	2,278	175.2
L 110X110X8	13.44	3	x	7	33	2,660	80.6	2	x	6	17	2,741	161.2
L 110X110X9	15.03	3	x	7	33	2,976	90.2	2	x	5	14	2,525	180.3
L 110X110X10	16.61	3	x	6	28	2,790	99.6	2	x	5	14	2,790	199.3
L 110X110X11	18.17	3	x	5	23	2,507	109.0	2	x	4	11	2,398	218.0
L 110X110X12	19.74	3	x	5	23	2,724	118.4	2	x	4	11	2,605	236.8
L 120X120X10,5	19.06	2	x	9	26	2,973	114.4	2	x	4	11	2,516	228.7
L 120X120X11	19.92	2	x	8	23	2,748	119.5	2	x	4	11	2,629	239.0
L 120X120X12	21.62	2	x	8	23	2,984	129.7	2	x	4	11	2,854	259.4
L 120X120X13	23.31	2	x	7	20	2,797	139.8	2	x	3	8	2,238	279.7
UPN 100	10.60	4	x	5	40	2,544	63.6	4	x	2	16	2,035	127.2
UPN 120	13.40	3	x	6	36	2,894	80.4	3	x	3	18	2,894	160.8
UPN 140	16.00	3	x	5	30	2,880	96.0	2	x	3	12	2,304	192.0
UPN 160	18.80	2	x	5	20	2,256	112.8	2	x	3	12	2,707	225.6
IPN 100	8.34	4	x	7	56	2,802	50.0	4	x	3	24	2,402	100.1
IPN 120	11.10	3	x	6	36	2,398	66.6	3	x	3	18	2,398	133.2
IPN 140	14.30	3	x	5	30	2,574	85.8	2	x	4	16	2,746	171.6
IPN 160	17.90	2	x	5	20	2,148	107.4	2	x	3	12	2,578	214.8
IPE 100	8.10	4	x	7	56	2,722	48.6	4	x	3	24	2,333	97.2
IPE 120	10.40	3	x	6	36	2,246	62.4	3	x	4	24	2,995	124.8
IPE A 120	8.70	3	x	6	36	1,879	52.2	3	x	4	24	2,506	104.4
IPE AA 120	8.40	4	x	7	56	2,822	50.4	3	x	4	24	2,419	100.8
IPE 140	12.90	3	x	5	30	2,322	77.4	3	x	3	18	2,786	154.8
IPE A 140	10.50	3	x	5	30	1,890	63.0	3	x	3	18	2,268	126.0
IPE AA 140	10.10	3	x	5	30	1,818	60.6	3	x	4	24	2,909	121.2
IPE 160	15.80	2	x	5	20	1,896	94.8	2	x	3	12	2,275	189.6
IPE A 160	12.70	2	x	5	20	1,524	76.2	2	x	4	16	2,438	152.4
IPE AA 160	12.10	2	x	5	20	1,452	72.6	2	x	4	16	2,323	145.2

		10 METERS
		Width		Height	Pieces Per Bundle	Theoric Bundle (kg)	Six Meters Weight (kg)
UPN 100	10.60	4	X	3	24	2,544	106.0
UPN 120	13.40	3	X	3	18	2,412	134.0
IPN 100	8.34	4	X	4	32	2,669	83.4
IPN 120	11.10	3	X	4	24	2,664	111.0

ÜRETİM STANDARTLARI ⇓

Production Standarts

TS 908

ASTM A6

DIN 1028

EN 10056

Production Standarts
TS 908	ASTM A6
DIN 1028
EN 10056

ÇELİK KALİTELERİ ⇓

Steel Grade
St 37-2 / St44 -2 / St52-3 S 235 JR / S 235 J0 / S 235 J2 S 275 JR / S 275 J0 / S 275 J2 S 355 JR / S 355 J0 / S 355 J2	ASTM A 36 ASTM A529 GR 50 ASTM A529 GR 55 ASTM A572 GR 42 ASTM A527 GR 50 ASTM A572 GR 55

Steel Grade

St 37-2 / St44 -2 / St52-3

S 235 JR / S 235 J0 / S 235 J2

S 275 JR / S 275 J0 / S 275 J2

S 355 JR / S 355 J0 / S 355 J2

ASTM A 36

ASTM A529 GR 50

ASTM A529 GR 55

ASTM A572 GR 42

ASTM A527 GR 50

ASTM A572 GR 55

UYGULANAN TESTLER ⇓

Mechanical Tests Tensile Test, Bending Test, Charpy Impact Test, Microstructure Test

Chemical Test Chemical analysis by spectrometer

SERTİFİKALARIMIZ ⇓

Mechanical Tests	Tensile Test, Bending Test, Charpy Impact Test, Microstructure Test
Chemical Test	Chemical analysis by spectrometer

images-430731713347celikkalitesipngpng-resim

MALZEME ÖZELLİKLERİ ⇓

Size	Unit Weight	Dimensions				Position of Axes					Surface		Section Properties
	Unit Weight	Dimensions				Position of Axes					Surface		Axis y-y / Axis z-z			Axis u-u		Axis v-v
	G (kg / m)	h=b (mm)	t (mm)	r1 (mm)	r2 (mm)	A (mm²) x 10²	zy=ys (mm) x 10	v (mm) x 10	u1 (mm) x 10	u2 (mm) x 10	AL m² / m	AG m² / t	ly=lz mm⁴ x104	Wel.y = Wel.z mm³ x10³	iy = iz mm x10	lu mm⁴ x104	iu mm x10	v mm⁴ x104	iv mm x10	lyz mm⁴ x104
L30x30x3	1,36	30	3	5	2,5	1,74	0,84	2,12	1,18	1,05	0,116	84,87	1,40	0,65	0,90	2,23	1,13	0,58	0,58	-0,83
L30x30x4	1,78	30	4	5	2,5	2,27	0,88	2,12	1,24	1,06	0,116	65,02	1,80	0,85	0,89	2,86	1,12	0,75	0,58	-1,05
L35x35x4	2,09	35	4	5	2,5	2,67	1,00	2,47	1,42	1,24	0,136	64,82	2,95	1,18	1,05	4,69	1,33	1,22	0,68	-1,73
L40x40x4	2,42	40	4	6	3,0	3,08	1,12	2,83	1,58	1,40	0,155	64,07	4,47	1,55	1,21	7,10	1,52	1,84	0,77	-2,63
L40x40x5	2,97	40	5	6	3,0	3,79	1,16	2,83	1,64	1,41	0,155	52,07	5,43	1,91	1,20	8,61	1,51	2,25	0,77	-3,18
L45x45x4,5	3,06	45	4,5	7	3,5	3,90	1,26	3,18	1,78	1,58	0,174	56,83	7,15	2,20	1,35	11,35	1,71	2,95	0,87	-4,20
L45x45x5	3,38	45	5	7	3,5	4,30	1,28	3,18	1,81	1,58	0,174	51,51	7,84	2,43	1,35	12,45	1,70	3,24	0,87	-4,60
L50x50x4	3,06	50	4	7	3,5	3,89	1,36	3,54	1,92	1,75	0,194	63,49	8,97	2,46	1,52	14,25	1,91	3,70	0,97	-5,28
L50x50x5	3,77	50	5	7	3,5	4,80	1,40	3,54	1,99	1,76	0,194	51,46	10,96	3,05	1,51	17,41	1,90	4,52	0,97	-6,45
L50x50x6	4,47	50	6	7	3,5	5,69	1,45	3,54	2,04	1,77	0,194	43,41	12,84	3,61	1,50	20,37	1,89	5,31	0,97	-7,53
L55x55x5	4,18	55	5	8	4,0	5,32	1,52	3,89	2,15	1,93	0,213	51,05	14,71	3,70	1,66	23,37	2,10	6,06	1,07	-8,66
L55x55x6	4,95	55	6	8	4,0	6,31	1,56	3,89	2,21	1,94	0,213	43,04	17,29	4,39	1,66	27,44	2,09	7,13	1,06	-10,16
L60x60x4	3,70	60	4	8	4,0	4,71	1,60	4,24	2,26	2,10	0,233	63,07	15,78	3,58	1,83	25,04	2,31	6,51	1,18	-9,26
L60x60x5	4,57	60	5	8	4,0	5,82	1,64	4,24	2,32	2,11	0,233	51,04	19,37	4,45	1,82	30,77	2,30	2,97	1,17	-11,40
L60x60x6	5,42	60	6	8	4,0	6,91	1,69	4,24	2,39	2,11	0,233	42,99	22,79	5,29	1,82	36,20	2,29	9,38	1,17	-13,41
L60x60x8	7,09	60	8	8	4,0	9,03	1,77	4,24	2,50	2,14	0,233	32,89	29,15	6,89	1,80	46,19	2,26	12,11	1,16	-17,04
L65x65x6	5,91	65	6	9	4,5	7,53	1,80	4,60	2,55	2,28	0,252	42,70	29,19	6,21	1,97	46,36	2,48	12,01	1,26	-17,17
L65x65x7	6,83	65	7	9	4,5	8,70	1,85	4,60	2,61	2,29	0,252	36,95	33,43	7,18	1,96	53,08	2,47	13,78	1,26	-19,65
L70x70x6	6,38	70	6	9	4,5	8,13	1,93	4,95	2,73	2,46	0,272	42,68	36,88	7,27	2,13	58,60	2,69	15,16	1,37	-21,72
L70x70x7	7,38	70	7	9	4,5	9,40	1,97	4,95	2,79	2,47	0,272	36,91	42,30	8,41	2,12	67,19	2,67	17,41	1,36	-24,89
L75x75x6	6,85	75	6	9	4,5	8,73	2,05	5,30	2,90	2,64	0,292	42,66	45,83	8,41	2,29	72,84	2,89	18,82	1,47	-27,01
L75x75x7	7,93	75	7	9	4,5	10,10	2,10	5,30	2,96	2,65	0,292	36,88	52,61	9,74	2,28	83,60	2,88	21,62	1,46	-30,99
L80x80x6	7,34	80	6	10	5,0	9,35	2,17	5,66	3,07	2,81	0,311	42,44	55,82	9,57	2,44	88,69	3,08	22,96	1,57	-32,87
L80x80x7	8,49	80	7	10	5,0	10,80	2,21	5,66	3,13	2,82	0,311	36,67	64,19	11,09	2,44	102,00	3,07	26,38	1,56	-37,81
L80x80x8	9,63	80	8	10	5,0	12,30	2,26	5,66	3,19	2,83	0,311	32,34	72,25	12,58	2,43	114,80	3,06	29,72	1,56	-42,52
L80x80x10	11,9	80	10	10	5,0	15,10	2,34	5,66	3,30	2,85	0,311	26,26	87,50	15,45	2,41	138,80	3,03	36,24	1,55	-51,27
L90x90x7	9,61	90	7	11	5,5	12,20	2,45	6,36	3,47	3,16	0,351	36,48	92,55	14,13	2,75	147,10	3,47	38,03	1,76	-54,52
L90x90x8	10,9	90	8	11	5,5	13,90	2,50	6,36	3,53	3,17	0,351	32,15	104,40	16,05	2,74	165,90	3,46	42,89	1,76	-61,50
L90x90x9	12,2	90	9	11	5,5	15,50	2,54	6,36	3,59	3,18	0,351	28,77	115,80	17,93	2,73	184,00	3,44	47,65	1,75	-68,79
L90x90x10	13,4	90	10	11	5,5	17,10	2,58	6,36	3,65	3,19	0,351	23,86	126,90	19,77	2,72	201,50	3,43	52,33	1,75	-74,59
L100x100x8	12,2	100	8	12	6,0	15,50	2,74	7,07	3,87	3,52	0,390	32,00	144,80	19,94	3,06	230,20	3,85	59,49	1,96	-85,35
L100x100x10	15,0	100	10	12	6,0	19,20	2,82	7,07	3,99	3,54	0,390	25,92	176,70	24,62	3,04	280,70	3,83	72,66	1,95	-104,00
L100x100x12	17,8	100	12	12	6,0	22,70	2,90	7,07	4,11	3,57	0,390	21,86	206,70	29,12	3,02	327,90	3,80	85,44	1,94	-121,30
L110x110x10	16,6	110	10	13	6,5	21,20	3,06	7,78	4,33	3,88	0,429	25,79	238,00	29,99	3,35	378,20	4,23	97,74	2,15	-140,20
L110x110x12	19,7	110	12	13	6,5	25,10	3,15	7,78	4,45	3,91	0,429	21,73	279,10	35,54	3,33	443,20	4,20	115,00	2,14	-164,10
L120x120x10	18,2	120	10	13	6,5	23,20	3,31	8,49	4,69	4,24	0,469	25,76	312,90	36,03	3,67	497,60	4,63	128,30	2,35	-184,60
L120x120x11	19,9	120	11	13	6,5	25,40	3,36	8,49	4,75	4,25	0,469	23,54	340,60	39,41	3,66	541,50	4,62	139,80	2,35	-200,90
L120x120x12	21,6	120	12	13	6,5	27,50	3,40	8,49	4,80	4,26	0,469	21,69	367,70	42,73	3,65	584,30	4,61	151,10	2,34	-216,60
L120x120x13	23,3	120	13	13	6,5	29,70	3,44	8,49	4,86	4,28	0,469	20,12	394,00	46,01	3,64	625,80	4,59	162,20	2,34	-231,80

American Sizes&Units Weights (kg/mt) of Equal Angles

Size		Thickness
inch		1/8"	3/16"	1/4"	5/16"	3/8"	7/16"	1/2"	5/8"
inch	mm	3,17 mm	4,76 mm	6,35 mm	7,93 mm	9,52 mm	11,10 mm	12,70 mm	15,87 mm
3/4* 3/4*	19,05	0,9 kg/mt
1* 1*	25,4	1,2 kg/mt	1,8 kg/mt	2,2 kg/mt
1 1/4* 1 1/4*	31,75	1,5 kg/mt	2,2 kg/mt	2,8 kg/mt
1 1/2* 1 1/2*	38,1	1,8 kg/mt	2,7 kg/mt	3,4 kg/mt
1 3/4* 1 3/4*	44,45	2,1 kg/mt	3,1 kg/mt	4,1 kg/mt
22 1/8"	50,8	2,4 kg/mt	3,6 kg/mt	4,7 kg/mt	5,8 kg/mt	7,0 kg/mt
2 1/2* 2 1/2*	63,5		4,6 kg/mt	6,1 kg/mt	7,4 kg/mt	8,7 kg/mt		11,4 kg/mt
3* 3*	76,2		5,5 kg/mt	7,3 kg/mt	9,1 kg/mt	10,7 kg/mt	12,4 kg/mt	14,0 kg/mt
3 1/2* 3 1/2*	88,9			8,6 kg/mt	10,7 kg/mt	12,6 kg/mt	14,6 kg/mt	16,5 kg/mt
4* 4*	101,6			9,8 kg/mt	12,2 kg/mt	14,6 kg/mt	16,8 kg/mt	19,0 kg/mt	23,4 kg/mt

*As per our customer’s request - tailor made

H-1 PAKETLEME ⇓

H-2 PAKETLEME ⇓

ÜRETİM STANDARTLARI ⇓

ÇELİK KALİTELERİ ⇓

UYGULANAN TESTLER ⇓

SERTİFİKALARIMIZ ⇓

MALZEME ÖZELLİKLERİ ⇓

American Sizes&Units Weights (kg/mt) of Equal Angles

Randevu Al
